Precision Integrated Casting Slipring Fast Transmission Slip Rings

Technical Parameters

Product Overview

SP013028 series, a series of small High-Speed Slip Ring is a cutting-edge electromechanical device engineered to transmit electrical power, signals, and data between stationary and rotating components at remarkable speeds, all within a compact form factor. Measuring just [X]mm in diameter and [X]mm in length, this slip ring defies traditional size constraints, making it an ideal choice for applications where space is at a premium.

Despite its diminutive size, it boasts an impressive maximum rotational speed of [X] RPM, ensuring seamless and reliable transmission even under extreme conditions. The slip ring features advanced contact materials and precision-machined components, which minimize electrical resistance, reduce wear, and extend the device’s lifespan. With excellent electrical insulation and high interference suppression capabilities, it can handle multiple channels of power and various signal types, including USB, Ethernet, and high-frequency signals, without compromising on transmission quality.

This small high-speed slip ring finds extensive use in diverse industries. In robotics, it enables continuous rotation and precise control, enhancing the flexibility of robotic arms. In the aerospace field, its lightweight and compact design meet the stringent requirements for airborne equipment. Additionally, it plays a crucial role in medical imaging devices, allowing for smooth rotation of components while maintaining accurate data transmission.

Designed for easy integration, our slip ring comes with customizable configurations to fit specific application needs. Whether you require a certain number of circuits, voltage ratings, or connection types, we can tailor the solution to ensure optimal performance. With rigorous quality control and testing, our Small High-Speed Slip Ring guarantees stable operation, high reliability, and consistent performance, providing you with a durable and efficient power and signal transmission solution.

• Superior Contact Material: The gold-gold contacts offer exceptional electrical conductivity and thermal conductivity, coupled with a low temperature coefficient of resistance. These contacts exhibit remarkable resistance to sulfurization, oxidation, and corrosive gases, ensuring long - term stable performance. Additionally, their optimal hardness provides excellent resistance to welding, arc corrosion, and burns, significantly enhancing wear resistance and reliability.

• Precision Integrated Casting: Our advanced integrated casting process ensures unparalleled concentricity between the ring groove and the bearing, with a tolerance of ≤ 0.01mm. This meticulous craftsmanship minimizes rotational vibrations and ensures smooth, consistent operation even at high speeds.

• Mirror - Finish Processing: Employing state - of - the - art mirror processing technology, we achieve an ultra - smooth contact surface on the slip ring, with a surface roughness of Ra0.02. This precision finish guarantees a more reliable electrical connection, reducing signal loss and enhancing overall transmission quality.

• High - Precision Component Manufacturing: Our slip rings are crafted using a precision component manufacturing process, with dimensional tolerances controlled within < 0.01mm. This high - precision engineering results in stable contact performance, minimizing electrical fluctuations and ensuring consistent power and signal transmission.

• Innovative Brush Design: Our uniquely designed brushes feature a near - zero pressure mechanism, which not only reduces friction but also extends the operational lifespan of the slip ring by up to one - third. This breakthrough design ensures prolonged service life without sacrificing performance.
• Compact and Space - Efficient Design: Despite its advanced technical features, the slip ring maintains a small footprint and a compact structure. This design flexibility allows it to seamlessly integrate into applications with stringent space constraints, making it the ideal choice for space - limited environments.
